Continuous Radon Sensing Using Airthings Wave

August 23, 20212 min read

📺 Watch the Video View on YouTube --- Radon Radon is everywhere, see map Naturally-occurring radioactive gas - causes lung cancer Inert, colorless...

ESP32 MQTT IoT BLE Bluetooth radon sensor debashish sahu

Watch on YouTube

📺 Watch the Video

View on YouTube

Radon

Radon is everywhere, see map
Naturally-occurring radioactive gas - causes lung cancer
Inert, colorless and odorless
•Naturally in the atmosphere in trace amounts
- Outdoors: radon disperses rapidly
•Most radon exposure occurs inside homes, schools and workplaces
- Indoors: Radon gas becomes trapped indoors after it enters buildings through cracks and other holes in the foundation
- Can be controlled and managed with proven, cost-effective techniques

Radon monitoring

Hardware

•Airthings Wave
- Continuous radon monitoring
- Long term monitoring
- LEDs color – radon level
- Battery Operated
- Bluetooth BLE
ESP32 - lolin D32 (can use any ESP32)
MQTT Server - Mosquitto

Software

Python script to read values from Airthings Wave: Wave-Reader
Home Assistant Custom Component: sensor.airthings_wave
ESP32 code to read Airthings BLE/Send MQTT: Airthings MQTT

schematic

Radon Mitigation

Since April 2020, we have observed high levels of radon (>2 pCi/L) which has prompted us to mitigate radon in the air we breathe in the house. This is in spite of having a passive radon mitigation system installed in the house when built.

•Seal the concrete basement
- Gray 1-part epoxy/vapor barrier
•Seal cracks and voids
- Gray 100% Silicone caulk
•Add radon mitigation system
- Radon Fan
- 3-prong appliance electrical cord
- 3’ rubber couplers
- Manometer

Results

Well below action limit of 2 pCi/L

results
